Settings Using the On Screen Display
Preparations
•Confirm that the TV is on and the VCR viewing channel
is selected.
•Turn on the VCR.
• Press VCFVTV to select the VCR mode.
(NV-HD620EA only)
On Screen Display
1 Press MENU.
O
2 Select OPTION. On Screen Display
ENTER
o
LANOUAGE
CtOCICECr'
»COSE CK SET
•OPTION
OEMONSTNATION
SELECT :DB.ENTER
END :*№NU
3 Select OSD.
cs:)
cs:)
■.OSO.- OK »OFF
SELECT
•E1B0 E1M E240 E2S0
TAPE SPEED «SP LP
SLUE BACK OH «OFF
~H-:m
END :HEKU
4 Select ON or OFF.
© ©
-.OSP.> 0№
tHPfeSELECir
•Else E1M EMO E28S
T№E№EB> «SP LP
BUISBWIC ON «OFF
:~l+ ;BB
ON: The on screen display will appear on the TV
screen.
OFF: The on screen display will not appear.
5 Press MENU twice to make the on screen display
disappear.
O
To use the on screen display:
Audio Output Mode Indicators
The Left (L) and Right (R) Indicators show which
sound mode is selected with AUDIO OUT.
Stereo: Both the Left (L) and Right (R) Indicators
appear.
Left: The Left (L) Indicator appears.
Right: The Right (R) Indicator appears.
Normal: Neither the Left (L) nor Right (R) Indicator
appears.
STEREO or BILINGUAL Indicator (NV-HO620A)
When receiving a TV programme, the type of sound
system in which it is broadcast is automatically
indicated.
STEREO, M1 and M2 Indicator (NV-HD620EA)
When receiving a TV programme with the NICAM
sound system, the type of sound system in which it is
broadcast is automatically indicated.
STEREO: When receiving a NICAM stereo
broadcast.
M1 M2: When receiving a NICAM dual-sound
broadcast.
When receiving a NICAM monaural
broadcast.
Ml:
Note:
The hear stereo performance connect as shown on
page 8 to a TV or Stereo Amplifier with left and right
audio inputs.
^ Programme position
O Tape running display
0)
CO
I
§
stop, Eject
Rewind, Review
Fast forward, Cue ►►
Playback ►
still playback I I
Recording •
Recording pause I I «
Slow playback
Repeat playback R ►
19
