3 BGP/MPLS IP VPN troubleshooting
Nortel Secure Router 8000 Series
_________ Troubleshooting - VPN
- If BGP VPNv4 peers establish between PEs, check whether VPN targets of the two
PEs match. The export VPN target of the local PE must be consistent with the import
VPN target of the remote PE. The import VPN target of local PE must be consistent
with the export VPN target. If not, modify the configuration.
- If BGP VPNv4 peers do not establish between PEs, the possible cause can be failure to
establish BGP peers between PEs. Use the display bgp peer command to view public
network BGP peers of PE. For information about the public network route problem
between PEs, see Nortel Secure Router 8000 Series Troubleshooting - IP Routing
(NN46240-706).
CD
NOTE
The VPNv4 routes between PEs are transferred by peers in the VPNv4 address family. The establishment
of BGP VPNv4 peers depends on BGP peers in the public network.
A
CAUTION
Specify the loopback interface used for BGP connection when you configure IGBP neighbors.
Use the peer peer-ip-address connect-interface loopback interface-number command to
specify IBGP peers.
On PE, check VPN routes of the remote CE. If you specify the next hop, but not the loopback
interface of the remote PE, the public network route cannot be associated with the LSP of the
public network.
If BGP configuration is correct and all BGP peers establish correctly, but no routes to the
remote CE are found by using the display ip routing-table vpn-instance command, the reason
is that no LSP is established between PE and the next hop of the routes to the remote CE. This
situation restricts the route from finding the associated LSP.
Use the display ip routing-table vpn-instance vpn-name ip-address [ mask | mask-length ]
verbose command, and you can find that the value of the tunnel ID is 0x0. The following is an
example:
Destination: 10.1.1.202/32
Protocol:
BGP
Process ID:
0
Preference:
255
Cost:
0
NextHop:
3.3.3.3
Interface:
NULL0
RelayNextHop:
0.0.0.0
Neighbour:
3.3.3.3
Label:
15360
Tunnel ID:
0x0
SecTunnel ID:
0x0
BkNextHop:
0.0.0.0
BkInterface:
BkLabel:
NULL
Tunnel ID:
0x0
SecTunnel ID:
0x0
State:
Inactive
Adv WaitQ Age:
00h01m05s
Tag:
0
Use the display bgp vpnv4 all routing-table label command on both the local PE and the
remote PE to check whether the labels at both the ends match. The private network label
assigned by the local PE is referred to as an incoming label for the local PE, and an outgoing
label for the remote PE.
If they match, go to Step 3.
