Switching Characteristics
Over the Industrial Operating Range
[6]
Parameter
Description
CY7C0430BV and CY7C0430CV
Unit
–133
–100
Min.
Max.
Min.
Max.
f
MAX2
[7]
Maximum Frequency
133
100
MHz
t
CYC2
[7]
Clock Cycle Time
7.5
10
ns
t
CH2
Clock HIGH Time
3
4
ns
t
CL2
Clock LOW Time
3
4
ns
t
R
Clock Rise Time
2
3
ns
t
F
Clock Fall Time
2
3
ns
t
SA
Address Set-up Time
2.3
3
ns
t
HA
Address Hold Time
0.7
0.7
ns
t
SC
Chip Enable Set-up Time
2.3
3
ns
t
HC
Chip Enable Hold Time
0.7
0.7
ns
t
SW
R/W Set-up Time
2.3
3
ns
t
HW
R/W Hold Time
0.7
0.7
ns
t
SD
Input Data Set-up Time
2.3
3
ns
t
HD
Input Data Hold Time
0.7
0.7
ns
t
SB
Byte Set-up Time
2.3
3
ns
t
HB
Byte Hold Time
0.7
0.7
ns
t
SCLD
CNTLD Set-up Time
2.3
3
ns
t
HCLD
CNTLD Hold Time
0.7
0.7
ns
t
SCINC
CNTINC Set-up Time
2.3
3
ns
t
HCINC
CNTINC Hold Time
0.7
0.7
ns
t
SCRST
CNTRST Set-up Time
2.3
3
ns
t
HCRST
CNTRST Hold Time
0.7
0.7
ns
t
SCRD
CNTRD Set-up Time
2.3
3
ns
t
HCRD
CNTRD Hold Time
0.7
0.7
ns
t
SMLD
MKLD Set-up Time
2.3
3
ns
t
HMLD
MKLD Hold Time
0.7
0.7
ns
t
SMRD
MKRD Set-up Time
2.3
3
ns
t
HMRD
MKRD Hold Time
0.7
0.7
ns
t
OE
Output Enable to Data Valid
6.5
8
ns
t
OLZ
[8]
OE to Low-Z
1
1
ns
t
OHZ
[8]
OE to High-Z
1
6
1
7
ns
t
CD2
Clock to Data Valid
4.2
5
ns
t
CA2
Clock to Counter Address Readback Valid
4.7
5
ns
t
CM2
Clock to Mask Register Readback Valid
4.7
5
ns
t
DC
Data Output Hold After Clock HIGH
1
1
ns
t
CKHZ
[9]
Clock HIGH to Output High-Z
1
4.8
1
6.8
ns
Notes:
6. If data is simultaneously written and read to the same address location and t
CCS
is violated, the data read from the address, as well as the subsequent data
remaining in the address is undefined.
7. f
MAX2
for commercial is 135 MHz. t
CYC2
Min. for commercial is 7.4 ns.
8. This parameter is guaranteed by design, but it is not production tested.
9. Valid for both address and data outputs.
