Basic GPS Operation
3-54
Basic GPS Operation
Chapter 3
3.11.3. NDB PAGES
Two pages of information may be displayed for each NDB in the KLN
89(B). Sample NDB pages are shown in figures 3-157 through 3-159.
3.11.3.1. The NDB 1 Page
See figure 3-157.
Line 1: The NDB identifier, preceded
by an arrow if it is the active waypoint.
To the right of the identifier is the
frequency of the NDB in kilohertz.
Line 2: The name of the NDB.
Lines 3-4: The latitude and longitude of the NDB
If the NDB is being viewed as part of
the nearest NDBs list (see section
3.8.1), the NDB 1 page format will
differ as follows (see figure 3-158):
Line 1: After the NDB identifier, the
number designating the NDB’s
position in the nearest NDB list is displayed. In figure 3-158, DFI is
the nearest NDB.
Lines 3-4: In place of the latitude/longitude, line 3 is blank and line 4
displays the magnetic bearing to or the magnetic radial from the NDB
and the distance. Placing the cursor over the radial/bearing field and
pressing
E
toggles between radial from and bearing to station.
3.11.3.2. The NDB 2 Page
See figure 3-159.
Line 1: The NDB identifier, preceded
by an arrow if it is the active waypoint.
Line 4: The magnetic bearing to or
the magnetic radial from the NDB and
the distance. Placing the cursor over the radial/bearing field and
pressing
E
toggles between radial from and bearing to station.
APT VOR NDB INT USR ACT NAV FPL CAL SET OTH
åå.ånm| DFI 1 246
ееееее|DEFIANCE
Leg|
NDB 1 |>021°To 2.3nm
Figure 3-158
APT VOR NDB INT USR ACT NAV FPL CAL SET OTH
åå.ånm| DFI
ееееее|
Leg|
NDB 2 |>021°To 2.3nm
Figure 3-159
APT VOR NDB INT USR ACT NAV FPL CAL SET OTH
åå.ånm| DFI 246
ееееее|DEFIANCE
Leg| N 41°20.07'
NDB 1 | W 84°25.62'
Figure 3-157
