4. Complete the waypoint entry
operation (figure 4-16).
NOTE: If adding a waypoint or way-
points (such as adding SID/STAR/
Approach procedures) would exceed
the capacity of FPL 0, KLN 89(B) will
notify you that it is deleting waypoints
from the beginning of FPL 0 to make
room for the addition.
5. Press F to display the waypoint
page on the right side for the
identifier just entered
(figure 4-17).
6. Press
F
again to approve the
waypoint page (figure 4-18).
7. Turn off the cursor (
B
).
4.1.5. DELETING A WAYPOINT FROM A FLIGHT PLAN
To delete a waypoint from a flight plan:
1. Press
B
to enable the cursor if
it is not on already.
2. Move the cursor over the
waypoint you wish to delete
(figure 4-19).
3. Press
E
. The letters Del
(delete) will appear to the left of
the identifier and a question mark
will appear to the right of the
identifier (figure 4-20). If a mis-
take was made and you do not
wish to delete this waypoint,
press
E
.
4. Press F and the waypoint will
be deleted from the flight plan.
The other waypoints in the flight
plan will be correctly repositioned
(figure 4-21).
5. Turn off the cursor ( B ).
Advanced GPS Operation
4-6
Advanced GPS Operation
Chapter 4
APT VOR NDB INT USR ACT NAV FPL CAL SET OTH
åå.ånm|Use? Inverted?
ееееее| 1:KNEW >Dis
# Leg| 2:GPT ----
*CRSR*| 8:KPIE ----
Figure 4-16
APT VOR NDB INT USR ACT NAV FPL CAL SET OTH
åå.ånm| GPT 109.90
ееееее|GULFPORT
# Leg| N 30°24.41'
VOR 1 | W 89°04.61'
Figure 4-17
APT VOR NDB INT USR ACT NAV FPL CAL SET OTH
åå.ånm|Use? Inverted?
ееееее| 2:GPT >Dis
Leg| 3:SJI 96
*CRSR*| 8:KPIE 497
Figure 4-18
APT VOR NDB INT USR ACT NAV FPL CAL SET OTH
åå.ånm|Use? Inverted?
ееееее| 2:SJI >Dis
Leg| 3:CEW 183
*CRSR*| 8:KPIE 497
Figure 4-19
APT VOR NDB INT USR ACT NAV FPL CAL SET OTH
åå.ånm|Use? Inverted?
ееееее| 2:SJI >Dis
# Leg|Del CEW 183
*CRSR*| 8:KPIE 497
Figure 4-20
APT VOR NDB INT USR ACT NAV FPL CAL SET OTH
åå.ånm|Use? Inverted?
ееееее| 2:SJI >Dis
Leg| 4:MAI 263
*CRSR*| 7:KPIE 497
Figure 4-21
