Solar Kit Installation Instructions
Copyright 2013 Talk-A-Phone Co.
• 7530 North Natchez Avenue • Niles, Illinois 60714 • Phone 773.539.1100 • [email protected] • www.talkaphone.com.
Page 2 of 25
All specifications are subject to change without notice. Talk-A-Phone is a registered trademark of Talk-A-Phone Co. All rights reserved.
Package 5: SLR-80-84 and SLR-120-84
24701: SLR-80-84 Panel Mounting Bracket Kit
24705: SLR-120-84 Panel Mounting Bracket Kit
Qty
.
Description
2
Bucket (Bracket)
4
Hose Clamp
2
Clip -Left (Bracket)
2
Clip -Right (Bracket)
2
Mounting Rail
4
Support Rail
4
1/4-
20 x 3/4” SS hex-cap bolt
4
1/4 flat washer, SS
8
1/4 split lock washer, SS
4
1/4 hex nut, SS
22
5/16-
18 x 3/4” SS hex-cap bolt
44
5/16 flat washer, SS
22
5/16 split lock washer, SS
22
5/16 hex nut, SS
1
1/4-
20 and 5/16 x 3/4” Spare Kit
Qty.
Part Number
Description
2
68594
42 Ah batteries
1
68681
Solar Controller
2
42855
10-24 Screws for mounting Solar Controller
2
42847
10-24 Nuts for mounting Solar Controller
6
67547
Terminal - Spade/Fork, #6 Tab, 12-10 AWG
20 ft
19678
Cable, Solar - 12AWG, Tray Cable, 2C, Black-Red
6
67545
Terminal - Ring , 0.25", 12-10 AWG
EITHER
1
68689
PV (photovoltaic) Module, 80W 12VDC (SLR-80-84 only)
1
24701
Panel Mounting Bracket for SLR-80-84
OR
1
68680
PV (photovoltaic) Module, 120-140W 12VDC (SLR-120-84 only)
1
24705
Panel Mounting Bracket for SLR-120-84
Qty.
Description
1
Large Bucket (Bracket)
1
Small Bucket (Bracket)
3
Hose Clamp
1
Clip
– Left (Bracket)
1
Clip
– Right (Bracket)
2
Mounting Rail
2
C-Bracket
2
Support Channel
– Inner
2
Support Channel
– Outer
10
1/4-
20 x 3/4” SS hex-cap bolt
2
1/4-
20 x 2” SS hex-cap bolt
2
1/4-
20 x 1 5/8” SS hex-cap bolt
16
1/4 flat washer, SS
4
1/4 split lock washer, SS
12
1/4-20 hex nut, SS
4
5/16-
18 x 3/4” SS hex-cap bolt
8
5/16 flat washer, SS
4
5/16 split lock washer, SS
4
5/16 hex nut, SS
1
1/4-
20 and 5/16 x 3/4” Spare Kit
