ASSEMBLY OF THE TIRE ONTO FRONT KNUCKLE
AND REAR HUB
Tire and Wheel
assembly
A-5O
Wheel Nut
A-5O
Wheel Nut
* Use the hex wrench came from
your kit to secure your tires.
INSTANT
GLUE INSTANT
GLUE
* Apply instant glue into the
both side of the groove of
the wheel. * Apply instant glue into the
both side of the groove of
the wheel.
( FRONT )
( FRONT )
( REAR )
( REAR )
ASSEMBLY OF THE BODY POST
3X 15mm
Screw
3X 15mm
Screw
#299
Body Post Set
#299
Body Support
Plastic
#299
Body Support
Plastic
#299
Body Support
Plastic
#299
Body Post
Plastic
#299
Body Post
Plastic
#299
Body Support
Plastic
#155B
Body Clip
#155B
Body Clip
#155B
Body Clip
#155B
Body Clip
