OFNA Racing Titan Twin User Manual
Page 20
A-41A
6mm Ball
A-41A
6mm Ball
A-41A
6mm Ball
A-41A
6mm Ball
3x8mm
Washer
3x8mm
Washer
3x8mm
Washer
3x8mm
Washer
3x30mm
Hex
Cap Screw
3x30mm
Hex
Cap Screw
3x16mm
Hex Screw
3x16mm
Hex Screw
3x16mm
Hex Screw
3x16mm
Hex Screw
M3
Nylon Nut
M3
Nylon Nut
ASSEMBLY OF THE FRONT AND REAR SHOCK
INTO SHOCK STAY
* ASSEMBLY 4 SHOCKS IN FRONT AND REAR.
