Assembly of the front and rear chassis skip plate, Front ) (rear ) – OFNA Racing Titan Twin User Manual
Page 21
4x20mm
Flat Head
Tapping Screw
4x20mm
Flat Head
Tapping Screw
3x12mm
Tapping Screw
3x12mm
Tapping Screw
40204
Skip Plate
40204
Skid Plate
3x20mm
Flat Head
Tapping Screw
3x20mm
Flat Head
Tapping Screw
3x20mm
Flat Head
Tapping Screw
3x20mm
Flat Head
Tapping Screw
ASSEMBLY OF THE FRONT AND REAR
CHASSIS SKIP PLATE
( FRONT )
(REAR )
