working with sound, pictures, and video 47
4-slot memory card reader
A
E
D B
C
Card Insert Into 4-slot reader
CompactFlash type I media Receptacle edge (holes) C (lower left)
CompactFlash type II media Receptacle edge (holes) C (lower left)
IBM Microdrive disk drive Receptacle edge (holes) C (lower left)
Secure Digital (SD) Memory Card Facing up D (upper right)
MultiMediaCard (MMC) Facing up D (upper right)
Memory Stick (MS) Memory Card Facing up E (lower right)
SmartMedia (SM) Memory Card Facing up B (upper left)
using your cd, dvd, and diskette drives
your drive options
Your PC has one or more of the following drives:
Drive What it does
CD-ROM Reads audio and data CD discs.
CD-RW or “cd writer” Reads and records (burns) audio and data CD discs.
DVD-ROM Reads audio and data CD and DVD discs.
DVD+RW/+R or
“dvd writer” Reads and records (burns) audio and data CD and DVD discs.
Combination Drive or
Combo drive Combines the functions of two drives into one. There are two
versions:
•
A DVD Writer drive and a CD-RW drive
Or
• A DVD-ROM drive and a CD-RW drive
Diskette (floppy) Reads and writes to a 3.5” diskette (floppy disk).
A In-use light
B Upper left slot
C Lower left slot
D Upper right slot
E Lower right slot
