2

BOLT KITS

Bolt Kit # 32-0120 and 32-0122 are provided wth 218-3 and 222-3. Check the bolt kit to be sure the following parts are included:

218-3

DESCRIPTION

4

Mounting Bracket

4

Stand

1

Crossmember w/ Airfoil

1

Crossmember w/o Airfoil

4

Clamp Bar

4

Mounting Pad

2

Roof Mounting Plate

2

Ladder Guide

2

Ladder Straps

PARTS LIST

222-3

DESCRIPTION

2

Stand

1

Crossmember w/o Airfoil

2

Center Mounting Bracket

2

Clamp Bar

2

Mounting Pad

1

Ladder Guide

Model

218-3

222-3

DESCRIPTION

Bolt Kit

32-0120

32-0122

Quantity

1

1

Installation Tool

4

4

1/4-20 Blind Fastener

1

1

1/4-20 x 2-1/4" Blk. Ox. Bolt

16

8

5/16-18 Nylon Lock Nut

32

16

5/16" Flat Washer

8

4

1/4-20 Nylon Lock Nut

4

4

1/4" Lock Washer

1

1

1/4" Flat Washer (yellow)

8

4

1/4-20 x 3/4" Hex Hd. Bolt

16

8

5/16-18 x 1" Carriage Bolt

1

1

1 oz. Tube E-6000 Sealant

8

4

Spacer - 1/8" thick

2

0

Roof Mounting Pad

3/8-16 x 1-1/4” Carriage Bolt
