If you purchased 8401 or 8402 Shelf Dividers,
install each Divider with two (2) 1/4-20 x 5/8"
Hex Head Bolts and 1/4-20 Nylon Lock Nuts
installed through the underside of the shelf.
NOTE: The side panels of the units have
pre-punched holes conveniently located for
installation of accessory items or to fasten to
other shelf units for additional strength. Extra
1/4-20 x 5/8" bolts and lock nuts have been
provided in the bolt kit for this purpose.
Place a drop of oil on the black oxide bolt before assembling as
shown on right. Place the Blind Fastener in the hole and use a
7/16" wrench to tighten black hex bolt until the Blind Fastener is
fully seated. When setting black hex bolt, it will start out hard.
As the Blind Fastener “bulbs” out it will get easier, until it bottoms
out or sets. Make sure the Blind Fastener and Installation Tool
do not turn during installation.
INSTALLATION INSTRUCTIONS FOR BLIND FASTENERS
Flat Washer
9/16” Wrench
Installation Tool
Blind Fastener
Black Oxide Bolt
7/16” Wrench
(Or 7/16” Socket)
WARNING
CAUTION
Prior to drilling, so as not to cut or puncture fuel tanks, fuel lines,
brake lines, electric wires, etc., check behind or underneath
drilling and mounting locations.
To keep debris out of your eyes when checking the underside of
the vehicle, or when drilling, always wear protective eyewear.
