PNOZ s8
Operating Manual PNOZ s8
21400-EN-07
7
Error indicators
Fault
Diagnostics: Internal error, unit defective
} Remedy: Switch supply voltage off and then on again, change unit if neces-
sary.
Faults - malfunctions
} Contact malfunctions: If the contacts have welded, reactivation will not be possible after
the input circuit has opened.
Technical details
General 750108 751108
Approvals CCC, CE, GOST, KOSHA, TÜV,
cULus Listed
CCC, CE, GOST, KOSHA, TÜV,
cULus Listed
Electrical data 750108 751108
Supply voltage
Voltage 24 V 24 V
Type DC DC
Voltage tolerance -20 %/+20 % -20 %/+20 %
Output of external power supply
(DC)
2,0 W 2,0 W
Residual ripple DC 20 % 20 %
Continuous duty 100 % 100 %
Max. overall cable resistance Rl-
max
Single-channel at UB DC 30 Ohm 30 Ohm
Voltage at
Input circuit DC 24,0 V 24,0 V
Current at
Input circuit DC 65,0 mA 65,0 mA
Number of output contacts
Instantaneous safety contacts
(N/O)
2 2
Inputs 750108 751108
Number 1 1
Semiconductor outputs 750108 751108
Number 1 1
Voltage 24,0 V 24,0 V
Current 20 mA 20 mA
