PNOZ s7
Operating Manual PNOZ s7
21399-EN-09
11
Mechanical data 750107 751107 751187
Cross section of external
conductors with screw ter-
minals
1 core flexible 0,25 - 2,50 mm², 24 - 12
AWG
– –
2 core with the same
cross section, flexible
with crimp connectors,
no plastic sleeve
0,25 - 1,00 mm², 24 - 16
AWG
– –
2 core with the same
cross section, flexible
without crimp connec-
tors or with TWIN crimp
connectors
0,20 - 1,50 mm², 24 - 16
AWG
– –
Torque setting with screw
terminals
0,50 Nm – –
Connection type Screw terminal Cage clamp terminal Cage clamp terminal
Mounting type plug in plug in plug in
Cross section of external
conductors with
spring-loaded terminals:
flexible with/without crimp
connector
– 0,20 - 2,50 mm², 24 - 12
AWG
0,20 - 2,50 mm², 24 - 12
AWG
Spring-loaded terminals:
Terminal points per con-
nection
– 2 2
Stripping length – 9 mm 9 mm
Dimensions
Height 98,0 mm 100,0 mm 100,0 mm
Width 17,5 mm 17,5 mm 17,5 mm
Depth 120,0 mm 120,0 mm 120,0 mm
Weight 170 g 170 g 170 g
The standards current on 2009-12 apply.
Safety characteristic data
Operating
mode
EN ISO
13849-1:
2006
PL
EN ISO
13849-1:
2006
Category
EN IEC
62061
SIL CL
EN IEC
62061
PFH
D
[1/h]
IEC 61511
SIL IEC 61511
PFD EN ISO
13849-1:
2006
T
M
[year]
Safety con-
tacts, instan-
taneous
PL e Cat. 4 SIL CL 3 2,31E-09 SIL 3 2,03E-06 20
All the units used within a safety function must be considered when calculating the safety
characteristic data.
