PNOZ s9
Operating Manual PNOZ s9
21401-EN-08
14
Environmental data 750109 751109 751189
Airgap creepage
In accordance with the
standard
EN 60947-1 EN 60947-1 EN 60947-1
Overvoltage category III III III
Pollution degree 2 2 2
Rated insulation voltage 250 V 250 V 250 V
Rated impulse withstand
voltage
6,00 kV 6,00 kV 6,00 kV
Protection type
Mounting (e.g. cabinet) IP54 IP54 IP54
Housing IP40 IP40 IP40
Terminals IP 20 IP 20 IP 20
Mechanical data 750109 751109 751189
Mounting position Any Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles 10,000,000 cycles
Material
Bottom PC PC PC
Front PC PC PC
Top PC PC PC
Cross section of external
conductors with screw ter-
minals
1 core flexible 0,25 - 2,50 mm², 24 - 12
AWG
– –
2 core with the same
cross section, flexible
with crimp connectors,
no plastic sleeve
0,25 - 1,00 mm², 24 - 16
AWG
– –
2 core with the same
cross section, flexible
without crimp connec-
tors or with TWIN crimp
connectors
0,20 - 1,50 mm², 24 - 16
AWG
– –
Torque setting with screw
terminals
0,50 Nm – –
Connection type Screw terminal Spring-loaded terminal,
plug in
Spring-loaded terminal,
plug in
Mounting type plug in plug in plug in
Cross section of external
conductors with
spring-loaded terminals:
flexible with/without crimp
connector
– 0,20 - 2,50 mm², 24 - 12
AWG
0,20 - 2,50 mm², 24 - 12
AWG
Spring-loaded terminals:
Terminal points per con-
nection
– 2 2
Stripping length – 9 mm 9 mm
