PNOZ s9
Operating Manual PNOZ s9
21401-EN-08
12
Relay outputs
750109
751109
751189
Max. current
6,0 A
6,0 A
6,0 A
Max. power
150 W
150 W
150 W
Safety contacts, AC1 at
240 V
240 V
240 V
Max. current
6,0 A
6,0 A
6,0 A
Min. current
0,01 A
0,01 A
0,01 A
Max. power
1500 VA
1500 VA
1500 VA
Safety contacts, DC1
at
24 V
24 V
24 V
Max. current
6,0 A
6,0 A
6,0 A
Min. current
0,01 A
0,01 A
0,01 A
Max. power
150 W
150 W
150 W
Utilisation category
In accordance with the
standard
EN 60947-5-1
EN 60947-5-1
EN 60947-5-1
Auxiliary contacts,
AC15 at
230 V
230 V
230 V
Max. current
5,0 A
5,0 A
5,0 A
Auxiliary contacts,
DC13 (6 cycles/min) at
24 V
24 V
24 V
Max. current
5,0 A
5,0 A
5,0 A
Safety contacts, AC15
at
230 V
230 V
230 V
Max. current
5,0 A
5,0 A
5,0 A
Safety contacts, DC13
(6 cycles/min) at
24 V
24 V
24 V
Max. current
5,0 A
5,0 A
5,0 A
Contact fuse protection,
external safety contacts
In accordance with the
standard
EN 60947-5-1
EN 60947-5-1
EN 60947-5-1
Blow-out fuse, quick
10 A
10 A
10 A
Blow-out fuse, slow
6 A
6 A
6 A
Circuit breaker,
24V AC/DC, character-
istic B/C
6 A
6 A
6 A
Contact fuse protection,
external auxiliary contacts
Blow-out fuse, quick
10 A
10 A
10 A
Blow-out fuse, slow
6 A
6 A
6 A
Circuit breaker, 24
V AC/DC, characteristic
B/C
6 A
6 A
6 A
Conventional thermal cur-
rent
6,0 A
6,0 A
6,0 A
Contact material
AgCuNi + 0,2 µm Au
AgCuNi + 0,2 µm Au
AgCuNi + 0,2 µm Au
