PNOZ s4.1
Operating Manual PNOZ s4.1
21890-EN-05
16
Times 750124 750154 751124 751154
Delay-on de-energi-
sation
With E-STOP typ. 10 ms 10 ms 10 ms 10 ms
With E-STOP
max.
20 ms 20 ms 20 ms 20 ms
With power failure
typ.
40 ms 40 ms 40 ms 40 ms
With power failure
max.
80 ms 80 ms 80 ms 80 ms
Recovery time at
max. switching fre-
quency 1/s
After E-STOP 50 ms 50 ms 50 ms 50 ms
After power fail-
ure
100 ms 100 ms 100 ms 100 ms
Waiting period with a
monitored reset
With rising edge 120 ms 120 ms 120 ms 120 ms
With falling edge 250 ms 150 ms 250 ms 150 ms
Min. start pulse du-
ration with a moni-
tored reset
With rising edge 30 ms 30 ms 30 ms 30 ms
With falling edge 100 ms 100 ms 100 ms 100 ms
Supply interruption
before de-energisa-
tion
20 ms 20 ms 20 ms 20 ms
Simultaneity, chan-
nel 1 and 2
∞ ∞ ∞ ∞
Environmental data 750124 750154 751124 751154
Climatic suitability EN 60068-2-78 EN 60068-2-78 EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature
range
-10 - 60 °C -10 - 60 °C -10 - 60 °C -10 - 60 °C
Storage temperature
Temperature
range
-40 - 85 °C -40 - 85 °C -40 - 85 °C -40 - 85 °C
EMC EN 60947-5-1, EN
61000-6-2, EN
61000-6-4
EN 60947-5-1, EN
61000-6-2, EN
61000-6-4
EN 60947-5-1, EN
61000-6-2, EN
61000-6-4
EN 60947-5-1, EN
61000-6-2, EN
61000-6-4
Vibration
In accordance
with the standard
EN 60068-2-6 EN 60068-2-6 EN 60068-2-6 EN 60068-2-6
Frequency 10,0 - 150,0 Hz 10,0 - 150,0 Hz 10,0 - 150,0 Hz 10,0 - 150,0 Hz
Max. amplitude 0,35 mm 0,35 mm 0,35 mm 0,35 mm
