PNOZ s4.1
Operating Manual PNOZ s4.1
21890-EN-05
13
Electrical data 750124 750154 751124 751154
Voltage at
Input circuit DC 24,0 V 24,0 V 24,0 V 24,0 V
Reset circuit DC 24,0 V 24,0 V 24,0 V 24,0 V
Feedback loop
DC
24,0 V 24,0 V 24,0 V 24,0 V
Current at
Input circuit DC 50,0 mA 50,0 mA 50,0 mA 50,0 mA
Reset circuit DC 50,0 mA 50,0 mA 50,0 mA 50,0 mA
Feedback loop 50,0 mA 50,0 mA 50,0 mA 50,0 mA
Number of output
contacts
Instantaneous
safety contacts
(N/O)
3 3 3 3
Auxiliary contacts
(N/C)
1 1 1 1
Inputs 750124 750154 751124 751154
Number 2 2 2 2
Semiconductor
outputs
750124 750154 751124 751154
Number 1 1 1 1
Voltage 24,0 V 24,0 V 24,0 V 24,0 V
Current 20 mA 20 mA 20 mA 20 mA
Relay outputs 750124 750154 751124 751154
Max. short circuit
current IK
1 kA 1 kA 1 kA 1 kA
Utilisation category
In accordance
with the standard
EN 60947-4-1 EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
Auxiliary contacts,
AC1 at
240 V 240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A 0,01 A
Max. current 1,5 A 1,5 A 1,5 A 1,5 A
Max. power 375 VA 375 VA 375 VA 375 VA
Auxiliary contacts,
DC1 at
24 V 24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A 0,01 A
Max. current 6,0 A 6,0 A 6,0 A 6,0 A
Max. power 150 W 150 W 150 W 150 W
Safety contacts,
AC1 at
240 V 240 V 240 V 240 V
Max. current 1,5 A 1,5 A 1,5 A 1,5 A
Min. current 0,01 A 0,01 A 0,01 A 0,01 A
Max. power 375 VA 375 VA 375 VA 375 VA
Safety contacts,
DC1 at
24 V 24 V 24 V 24 V
Max. current 6,0 A 6,0 A 6,0 A 6,0 A
Min. current 0,01 A 0,01 A 0,01 A 0,01 A
Max. power 150 W 150 W 150 W 150 W
