24 Customer Care Center 1-800-732-2677 www.petsafe.net 25
PROGR
AMMING
PROGR
AMMING
Re-latch Time: Default re-latch time is 2 seconds but can be changed from 1 second to 60 seconds for each pet and is useful if you have an older
or slower pet. If Master Mode is selected as the individual pet access mode, then the individual re-latch time cannot be adjusted.
In-Tone: Default is off but 10 tone options available. If Master mode is selected as the individual pet access mode, then the individual in-tone
cannot be adjusted.
Out-Tone: Default is off but 10 tone options available. If Master mode is selected as the individual pet access mode, then the individual out-tone
cannot be adjusted.
Pet Access Mode (Individual Pet)
The Access Mode can be programmed for each individual pet wearing a programmed Passport Key ™ . This allows you to customize access based
on each of your pet’s needs. The Access Mode options available are:
Master: Under each individual pet, when Master mode is selected, the pet will be programmed to all settings under Master Access including
Access Mode, Re-latch Time, In-Tone and Out-Tone. Master is factory default individual Pet Access Mode.
In/Out: Allows a pet with a programmed Passport Key ™ to enter and exit the Passport ™ as they please.
In Only: Allows a pet with a programmed Passport Key ™ to enter but not exit the Passport ™ .
Out-Only: Allows a pet with a programmed Passport Key ™ to exit but not enter the Passport ™ .
Timer: Allows the other pet access modes (In/Out, In-Only, Out-Only) to be programmed at specific times of day by pet if wearing a programmed
Passport Key
™ . Four programmable time slots available with a minimum of two programmed times required.
To Change Pet Access Mode:
1. From Main Menu select Setup > Pet Settings > Pet n (or name of
Pet) > Pet Access. Use right arrow to select.
2. Use right arrow key to scroll through Pet Access Modes to select
desired mode: Master, In/Out, In-Only,Out-Only or Timer.
Press left arrow/back key to return to Main Menu.
If Master Mode is selected, all other setting options under the
Pet’s menu will not show on the screen because they cannot be changed.
These settings for the pet will default to the ones under Master Access
(see “Master Access” page 20). If Timer Mode is selected, Access Times must be set with a minimum of two programmed times required (see
“Timer Mode” page 24).
Timer Mode (Individual Pet)
Timer mode under each pet allows you to set the Passport ™ to one of the other access options (In/Out, In-Only, or Out-Only) for that specific pet
Setting Timer Mode:
1. From Main Menu select Setup > Per Settings > Pet n (or pet’s
name) > Mode.
2. Press right arrow key to scroll to Timer option to select.
3. Once Timer Mode has been selected, Access Time will appear at the
bottom of the Pet n Menu list. Use down arrow key to highlight Access
Time then right arrow key to select.
4. The Access Time screen will list four available time slots. Press right
arrow key to select first time slot.
5. The first line listed on Access Time menu is to select the pet access mode.
Use right arrow key to scroll through and select desired pet access
mode:
In/Out, In-Only or Out-Only.
6. Use down arrow key to highlight Time. Press right arrow key to enter
specific time for your pet to have type of access you just selected in
Step 5. After you use arrow keys to enter desired time, press enter key to
accept. Press left arrow/back key to return to Access Time menu screen.
7. Use down arrow key to highlight second time slot. Press right arrow
key to select. Repeat Steps 5 & 6 to select pet access mode and schedule time for the access. Repeat
steps for as many times as you want to schedule.
Remember a minimum of 2 programmed times
are required but up to 4 time slots are available. After you select and enter desired access options and
scheduled times, review the Access Time menu screen to make sure what you entered is correct.
Note:
If 2 time slots have NOT been programmed, you will receive an error screen. The Pet Access
Mode will then default back to In/Out Mode.
Timer Mode Example: It might be helpful to think of Timer Mode in the form of a 24 hour or clock timeline. If
you want your pet to have full access during the daytime (for example, from 7 am in the morning until the late
evening) but want your pet indoors at night (for example, starting at 7 pm), you would want to set that specific
pet’s access mode to
In/Out at 7 am and to In-Only access mode at 7 pm.
After using Timer Mode to
program the example listed,
this is what the Access Time
menu screen would display:
To Remove Timer Mode Access Time:
1. From Main Menu select > Setup > Pet Settings > Pet n > Pet
Access > Mode.
2. Press right arrow key to scroll to Timer option to select.
3. Once Timer has been selected, Access Time will appear at bottom of
Pet n menu list. Use down arrow key to highlight Access Time then
right arrow key to select.
4. Use up and down arrow keys to highlight which Access Time slot you
wish to remove. Press right arrow key to select.
5. Use down arrow key to highlight Remove and right arrow key to select. The time slot on the Access Time Menu should now be removed.
Please remember you must have a minimum of two programmed Access Times entered for Timer Mode to work.
Timer Mode can be disabled by setting a different Pet Access Mode, while keeping the programmed Timer Mode settings. This might be
useful if you want to use Timer Mode during the week for a specific pet and a different Pet Access Mode on the weekend.
Re-latch Time (Individual Pet)
The Re-latch Time is the amount of time it takes the pet door flap to re-lock after the Passport Key ™ is no longer
detected. The factory default Re-latch Time is set to 2 seconds but can be changed from 1 second to 60
seconds for each pet. This is especially useful if you have an older or slower pet who may need more time than
other pets to go through the flap before it re-locks.
The Re-latch Time can only be changed by pet if the individual pet access mode is NOT set to Master.
To Change Re-latch Time:
1. From Main Menu select Setup > Pet Settings > Pet n (or pet name). Use right arrow key to select.
2. Press down arrow key to highlight Relatch Time then use right arrow key to scroll through to find desired Re-latch Time. Press left arrow/back
key to return to Main Menu.
In-Tone & Out-Tone (Individual Pet)
Optional audible alerts can also be set by pet to let you know when a pet enters or exits with the In-Tone and Out-Tone settings. The default factory
setting for both In-Tone and Out-Tone is Off, but these can easily be changed to one of 10 audible tones. This is helpful if you want to know when a
specific pet comes in or goes out using the Passport
™ .
In-Tone and Out-Tone can only be changed by pet if the individual pet access mode is NOT set to Master. Door Operational Mode must
be set to Smart Mode for In-Tone and Out-Tone to work (see “Door Operational Modes” page 19).
12 am 7 am 12 pm 7 pm 11 pm
In Only
In/Out
Example:
Note:
Note:
Note:
