Specifications
Item Specification
Dimensions, including
rubber feet (length x height
x width)
32.5 x 8 x 18.8 cm (12.8 x 3.1 x 7.4 in.)
Weight 2.0 kg (4.4 lb)
Keyboard type (power,
auto ECG, and rhythm ECG
buttons)
Polyester overlay
Display
Type
Resolution
TFT, 11 cm (4.3 in.) color touch screen
WQVGA, 480 x 272
Thermal paper
Z-fold
Roll
11.4 cm (4.5 in.) x 250 sheets
11.4 cm (4.5 in.) x 20 m
Thermal printer (internal) Computer-controlled dot array, 8 dots/mm
Thermal-chart-paper
speeds
10, 25, 50 mm/s
Gain settings
Auto ECGs
Rhythm ECGs
2.5, 5, 10, 20 mm/mV, AUTO
2.5, 5, 10, 20 mm/mV
Lead configurations Standard, Cabrera
Report formats, internal
printer*
Auto ECGs
Rhythm ECGs
Average cycles
3x4 @ 25 mm/s, 3x4 @ 50 mm/s, 3x4 + 1R @ 25 mm/s, 3x4 - 5.0s @ 25 mm/s,
3x4 - 5.0s @ 50 mm/s, 2x6 - 1.6s @ 25 mm/s, No print
3 leads
3x4 + 3R @ 25 mm/s, 3x4 + 3R @ 50 mm/s, 2x6 + 1R @ 25 mm/s,
2x6 + 1R @ 50 mm/s, No print
