Connecting to an external USB printer (optional - available
with CP 50 Plus only)
You can connect a CP 50 Plus electrocardiograph to an external printer. The printer must
be a USB inkjet or laser printer that supports PCL3 and PCL5 (printer control languages).
No special software is required.
The external printer prints auto ECG reports, always in black and white. (Rhythm ECGs
always print to the internal printer.)
Cables longer than three meters have not been verified for use with the
electrocardiograph. Do not use cables longer than three meters.
To connect to an external USB printer
1. Connect one end of a USB cable to the printer’s USB connector, and connect the
other end to the electrocardiograph’s USB connector.
2. Enable the external printer.
a. Touch the menu button.
b. Touch Settings > ECG > Auto report 1 or Auto report 2.
c. Under Printer, select External.
Connecting to a CardioPerfect workstation (optional,
available with CP 50 Plus only)
You can connect a CP 50 Plus electrocardiograph to a Welch Allyn CardioPerfect
workstation via USB cable or via Ethernet cable. Software provided in the Connex
Software Connectivity Kit is required to communicate with the Welch Allyn CardioPerfect
workstation. After you connect, you can perform several functions from the
electrocardiograph, including:
•
Send ECG tests to the workstation.
• Search for patient data in the workstation database.
Cables longer than three meters have not been verified for use with the
electrocardiograph. Do not use cables longer than three meters.
Directions for use Setup 17
