48 Chapter 5 Performing ECG Tests Welch Allyn CP 100 Electrocardiograph
Recording an Auto ECG
An Auto ECG is a report typically showing a 10-second acquisition of 12 leads of ECG
information combined with patient data, interpretation, and measurements matrix. To
learn how to set up the Auto ECG report format, see
“About Auto ECG Reports” on
page 33.
As shown in the following diagram, there are the two types of Auto ECG: normal and stat.
For details, see these procedures:
• “Recording a Normal Auto ECG” on page 49
• “Recording a Stat Auto ECG” on page 53
Figure 31. Auto ECG Testing, Process Diagram
Auto ECG Post-Print
screen.
Enter patient data.
Auto Report prints.
Normal Stat
Press quickly. Press and hold.
