22 WACS outbound HL7 protocols Welch Allyn Connectivity Server
Outbound vital-sign tags and filters
WACS generates the vital-sign tags and filters described in this section.
By default, missing tags or tag errors cause the HL7 interface to reject the request or
query. If part of a message or reply is valid, WACS ignores or rejects the erroneous
portion and returns only the valid reply.
This setting is configurable in the WACS HL7 Manager pages (see the Welch Allyn
Connectivity Server directions for use).
Vital-sign tags
Vital-sign tags include vital sign name tags, unit tags and optional status fields.
Table 11. WACS HL7 sublevel tags for vital signs (OBX-4)
Vital-sign sub-level HL7 OBX-4 tag
Temperature 1 (Temperature) 1
Temperature 2 (Temperature) 2
Systolic Blood Pressure (IBP-1, IBP-2, NIBP) SYS
Diastolic Blood Pressure (IBP-1, IBP-2, NIBP) DIA
Mean Blood Pressure (IBP-1, IBP-2, NIBP) MEAN
Table 12. WACS HL7 tags for units (OBX-6)
BPM (1 / min)
DegC (°C)
DegF (°F)
Percent (%)
mmHg
kPa
Br/M (1 / min)
PVC/Min (1 / min)
Table 13. Optional WACS HL7 status fields (OBX-8 abnormal flag segment)
OBX-8 abnormal
flag segment Patient monitor/Acuity
System notation Description
Valid value
< (---) Under range, below absolute low on the instrument scale
> (+++) Over range, above absolute high on the instrument scale
? Invalid For example, no valid SpO2 numeric is produced when the SpO2
sensor is removed from the patient’s finger.
