A. C. MODULAR GENERATOR SYSTEM
Page 36 of 49
Time Since last Oil Filter
Change in Hours.
Press Mode until FLt
and Xr are displayed
Example of oil filter run time display
Figure 28
4. The Command & Control Center will flash a fault when 250 hours have passed
since the previous filter change. After replacing the filter, this fault can be removed
from the Command & Control Center, and the filter run time can be reset by
performing the following steps:
Step a: Press Mode until
InF,
0IL
,
and FILt appear.
Step b: Hold Mode switch
down and press On/Off three
times in a row to clear the
fault.
Procedure will also work
in the Oil Filter Hours
Information display
Example of oil filter service warning display
Figure 29
