40

420HE Installation Manual

7.3

Continuous Output (Stream) Format

Figure 7-1 shows the continuous output format sent to the

420HE

EDP or printer port when the STREAM

parameter (SERIAL menu) is set to either EDP or PRN.

ASCII 02
(decimal)

Weight data: 7 digits, right-justified, with
decimal point, l eading zer o s upr e ssion.
Overload = ^^^^^^^
Underrange = ] ] ] ] ] ] ]
Display overflow = OVERFL

L = pounds
K = kilogram
T = ton
G = grams
O = ounces
= none

G = Gross
N = Net

Status:
< space > = valid
I = Invalid
M = Motion
O = Over/under range

Polarity:

< space > = Positive
<–> = Negative

<^> = Overload

<]> = Underrange

or

ASCII 13, 10

(decimal)

Figure 7-1. Continuous Output Data Format
