10 420HE Installation Manual
2.7 Replacement Parts
Table 2-5 lists replacement parts for the 420HE , including all parts referenced in Figures 2-5 and 2-6.
Table 2-5. Replacement Parts
Ref
Number PN Description (Quantity) Figure
1 14842 Screws, 32NC x 5/16 (6) See Figure 2-5 11
2 87962 Enclosure (1)
3 58248 Lock nut, hex 32NC
4 82856 Power supply bracket (1)
5 72996 Power supply, 12V board (1)
6 14822 Screws, 40NC x 1/4 (4)
7 16774 Fuse cover, 5 x 20mm (1)
8 58096 Standoffs, female - female (6)
9 87808 LED display board, 2 in. high (1)
10 14839 Screws, 32NC x 1/4 (11)
11 14875 Screws, 32NF x 3/8 (10)
12 87966 Panel assembly, mounting (1)
13 87958 CPU board (1)
15 15655 Cable grips, 8 NPT (3)
16 15656 Lock nut, 8 NPT (3)
17 85202 Power cord, 120 VAC (1) See Figure 2-6 12
18 87971 Switch assembly, 6 pushbutton (1) See Figure 2-5 11
19 87969 Filter lens (1)
20 15895 Switch cover, SRVR NEMA 4X (6)
21 87967 Cable assemly (1) See Figure 2-6 12
22 15650 Cable tie mounts, 3/4 in. (8)
23 88189 Switch cable assembly (1)
24 88191 Ribbon cable, 17 in, (1)
26 16892 Earth ground label (1)
27 19538 Post only, slotted black (2)
28 87968 Overlay panel (1)
29 14626 kep nuts, 32NC hex (1)
30 15134 Lock washer, no. 8, type A (1)
31 15631 Cable ties, nylon, 3 in. (10)
54224 Fuse, 4 Amp, 250V, 5x20mm (1)
30911 Mounting Foot Kit (1)
85555 Annunciator Labels (2)
15664 Cord grip reducing glands, less than 1/4 in. cable size (3)
87972 Operation manual (1)
