30 420HE Installation Manual
5.1.2 Reporting Commands
Reporting commands (see Table 5-2) send specific
information to the EDP port. These commands can be
used in both setup mode and normal mode.
Table 5-2. EDP Reporting Commands
Command Function
DUMPALL List all parameter values
VERSION 420HE software version
P Write current displayed weight with units
identifier. See Section 7.2 on page 39 for
more information.
ZZ Write current weight and annunciator
status. See Section 7.2 on page 39 for
more information.
S Write one frame of stream format. See
Table 5-12 on page 33 for information
about the SX and EX commands.
5.1.3 The RESETCONFIGURATION Command
The RESETCONFIGURATION command can be used
to restore all configuration parameters to their default
values. Before issuing this command, the indicator
must be placed in test mode (press and hold setup
switch for approximately three seconds to show TEST
menu).
This command is equivalent to using the DEFLT
function on the TEST menu. See Section 7.9 on
page 47 for more information about test mode and
using the TEST menu.
Note
All load cell calibration settings are lost when
the RESETCONFIGURATION command is run.
5.1.4 Parameter Setting Commands
Parameter setting commands allow you to display or
change the current value for a particular configuration
parameter (Tables 5-3 through 5-11).
Current configuration parameter settings can be
displayed in either setup mode or normal mode using
the following syntax:
command
Most parameter values can be changed in setup mode
only. Use the following command syntax when
changing parameter values:
command=value
where value is a number or a parameter value. Use no
spaces before or after the equal (=) sign. If you type an
incorrect command or value, the display reads
?? .
Changes to the parameters are saved as they are entered
but typically do not take effect until you exit setup
mode.
For example, to set the motion band parameter to 5,
type the following:
MOTBAND=5D
5.1.5 Soft Reset
The command RS will reset the indicator without
losing configuration and calibration. It does reset
consecutive number.
Table 5-3. CONFIG EDP Commands
Command Description Values
GRADS Graduations 1–100 000
ZTRKBND Zero track band OFF, 0.5D, 1D, 3D
ZRANGE Zero range 1.9%, 100%
MOTBAND Motion band 1D, 2D, 3D, 5D, 10D, 20D, OFF
OVRLOAD Overload FS+2%, FS+1D, FS+9D, FS
SMPRAT Sample rate 15HZ, 30HZ, 60HZ, 7.5HZ
DIGFLTR1
DIGFLTR2
DIGFLTR3 Digital filtering 1, 2, 4, 8, 16, 32, 64
DFSENS Digital filter cutout sensitivity 2OUT, 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
DFTHRH Digital filter cutout threshold NONE, 2DD, 5DD, 10DD, 20DD, 50DD, 100DD, 200DD, 250DD
TAREFN Tare function BOTH, NOTARE, PBTARE, KEYED
