LOCKOUT Locks out the keypad of the calibrator in remote operation
LO_ERR Sets the 0% of span limit for percent error mode
LO_ERR Returns the 0% of span limit for percent error mode
OHMS? Returns ohms value measured from the RTD
PRES_UNIT Set the pressure unit for the indicated display
PRES_UNIT? Returns the pressure from the indicated display
REMOTE Puts the calibrator in remote mode
RTD_TYPE Sets the RTD type
RTD_TYPE? Returns the RTD type
ST_START Starts a switch test
ST_OPEN? Returns pressure value at which the switch opened
ST_CLOSE? Returns pressure value at which the switch closed
ST_DEAD? Returns pressure value of the deadband of the switch
TEMP_UNIT Set the RTD to read in °F or °C on the indicated display
TEMP_UNIT? Returns the unit the RTD is set to read on the indicated
display
VAL? Returns the measured values
ZERO_MEAS Zeros the pressure module
ZERO_MEAS? Returns the zero offset of the pressure module
Table 7: Parameter units
Units Meaning
MA milliamps of current
V Voltage in volts
CEL Temperature in Celsius
FAR Temperature in Fahrenheit
OHM Resistance in Ohms
PSI Pressure in pounds per square-inch
INH2O4C Pressure in inches of water at 4°C
INH2O20C Pressure in inches of water at 20°C
INH2O60F Pressure in inches of water at 60°F
CMH2O4C Pressure in centimeters of water at 4°C
CMH2O20C Pressure in centimeters of water at 20°C
BAR Pressure in bars
MBAR Pressure in millibars
MPAL Pressure in MegaPascals
KPAL Pressure in kiloPascals
