2
General Safety
Do not operate or work on this equipment unless you have read and understand the
instructions and warnings in this manual. Failure to follow the instructions or heed the
warnings could result in injury or death. Contact any Rice Lake Weighing Systems dealer for
replacement manuals. Proper care is your responsibility.
Before attempting to operate this unit, make sure every individual who operates or works with this unit has
read and understands the following safety information.
Failure to heed may result in serious injury or death.
DO NOT allow minors (children) or inexperienced persons to operate this unit.
DO NOT operate without all shields and guards in place.
DO NOT jump on the scale.
DO NOT use for purposes other than weight taking.
DO NOT place fingers into slots or possible pinch points.
DO NOT use any load bearing component that is worn beyond 5% of the original dimension.
DO NOT use this product if any of the components are cracked.
DO NOT exceed the rated load limit of the unit.
DO NOT make alterations or modifications to the unit.
DO NOT remove or obscure warning labels.
DO NOT use near water.
Before opening the unit, ensure the power cord is disconnected from the outlet.
Keep hands, feet and loose clothing away from moving parts.
Use only AC power (rated value) and the dedicated AC adapter.
1.2 Standard Features
• External weight calibration
• Large 16.5 mm high liquid crystal backlight display
• Selectable modes: weight, unit, count and percentage
• 12 units of measurement
• Mono-Metal Tuning Fork Sensor (MMTS) provides quick response and stability
• 20-step bar graph display
• 115VAC adapter included (230VAC optional)
• RS-232 bidirectional
• Plastic housing on models less than 1000g; plastic top and die cast housing on models greater than 1000g
1.3 Component Parts
Round-pan types: TP-220, TP-320, TP-420, TP-620, TP-220, TP-420, TP-620
Square-pan types: TP-820, TP-1200, TP-2200, TP-3200, TP-4200, TP-6200, TP-8200, TP-12K, TP-2200, TP-4200
Part #
Model #
Description
NTEP Resolution
108155
TP-420NT
420g x 0.001g
(e=0.01g)
163604
TP-1200NT
1200g x 0.01g
(e=0.1g)
108154
TP-4200NT
4200g x 0.01g
(e=o.1g)
163606
TP-6200NT
6200g x 0.01g
(e=0.1g)
Table 1-1. Part Number Information
WARNING
