Functions Setup 19
3.4.2
Interface Specifications
3.4.3
Output Data
Data Format
By changing the function settings on the main unit of the balance, users can select either a six-digit numeric format or a seven-
digit numeric format.
1. Six-digit numeric format is composed of 14 characters, including the terminators CR=0DH, LF=0AH.
2. Seven-digit numeric format is composed of 15 characters, including the terminators CR=0DH, LF=0AH. A parity bit
can also be appended.
Polarities (P1: one character)
Numeric Data
Six-digit numeric format (D1-D7; seven characters)
Seven-digit numeric format (D1-D8; eight characters)
1
Transmission System
Serial transmission with start-stop synchronization
2
Transmission rates
1200/2400/4800/9600 bps
3
Transmission codes
ASCII codes (8-bit)
4
Signal levels
Compliant with EIA RS-232C
HIGH level (Data logic 0) +5 to +15 V
LOW level (Data logic 1) -5 to -15 V
5
One-character bit configuration
Start bit: 1 bit
Data bit: 8 bits
Parity bit: 0/1 bits
Stop bit: 2 bits
6
Parity bit
None/odd/even
1
2
3
4
5
6
7
8
9
10
11
12
13
14
P1
D1
D2
D3
D4
D5
D6
D7
U1
U2
S1
S2
CR
LF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
P1
D1
D2
D3
D4
D5
D6
D7
D8
U1
U2
S1
S2
CR
LF
P1
Code
Description
+
2BH
When data is zero or positive
-
2DH
When data is negative
(SP)
20H
When data is zero or positive
D1-D7 (D8)
Code
Description
0-9
30H-39H
Numerical value 0-9
2EH
Decimal point (floating position)
When the data is an integer, it may be omitted
and replaced with a blank space (SP) in the
lowest-order place.
(SP)
20H
Space: zero of leading portion of value (leading zero suppress)
LSB
MSB
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
Logic “1”
Logic “0”
Data bit
Start bit
Parity bit
(may be omitted)
Stop bit
Note
