20 TP Series Balance
Units (U1, U2: Two Characters)
All codes are ASCII codes.
Result of Judgment when operating the balance with the limit function (S1: One Character)
Status (S2: One Character)
3.4.4 Input commands
Users can control the balance remotely by transmitting commands from an external device. Two types of control commands
are available: instruction for tare subtraction and setup of output control.
Command Transmission Method
1. A command is transmitted to the balance from an external device. Since the data flow (transmission and reception) is
stored by a full-duplex system, commands can be transmitted regardless of their data transmission timing.
2. When the balance has executed the received command, it activates a normal end response or transmits the requested
data via the transmitting command. If the balance was unable to execute the command or received an erroneous
command, it transmits an error and response. If the balance is working properly, it usually returns a response within a
second after it receives the transmitted command. If the balance receives a transmission while it is conducting a
procedure (such as the setup of a function or a span adjustment), it will transmit a response when the procedure
finishes.
3. When transmitting more than one command to the balance from a remote device, wait until a confirmation on the first
transmission is received before transmitting the next.
U1 U2 Code Meaning Balance Indicators
(SP) G 20H 47H Gram g
C T 43H 54H Carat 
O Z 4FH 5AH Ounce 
L B 4CH 42H Pound 
O T 4FH 54H Troy Ounce 
D W 44H 57H Pennyweight

G R 47H 52H Grain
►
(lower right)
T L 54H 4CH tael (Hong Kong) 
T L 54H 4CH tael (Singapore, Malaysia)  ►
(upper right)
T L 54H 4CH tael (Taiwan) 
►
(lower right)
M O 4DH 4FH Momme Mom
t o 74H 6FH Tola 
(SP) % 20H 25H Percentage %
P C 50H 43H Pieces Pcs
S1 Code Description
L 4CH LO (Low)
G 47H OK (Good)
H 48H HI (High)
(SP) 20H No limit value specified
S2 Code Description
S 53H Data stable
U 55H Data unstable
E 45H Data error (data other than S2 is invalid)
(SP) 20H No status specified
