7. Product Description
KBox B-101 – User’s Guide (Version 1.00)
7.3. Right/Left and Top Side
At the right and left side of the chassis, the threaded holes for attaching the optional mounting brackets are located. In
addition, the type label is attached to the left side of the chassis.
2
2
4
3
1
Fig. 13: Right side of the
chassis
Fig. 14:Top side of the chassis
Fig. 15: Left side of the chassis
1 Right side of the chassis
2 Threaded holes for attaching the mounting
brackets
3 Top side of the chassis (cover)
4 Left side of the chassis (with type label)
