7. Product Description KBox B-101 – User’s Guide (Version 1.00)
7.1.3.4.
Display Port Connector
Two external (digital) displays can be connected to the DisplayPort connectors (DP0, DP1) (Fig. 11, pos. 6).
Appropriate Monitors can be connected directly to the DisplayPort connectors using DisplayPort
cables. To avoid disturbances, it is recommended not to use any adapters (e.g. DisplayPort/DVI or
DisplayPort/HDMI adapter) at the DisplayPort connectors.
7.1.3.5.
Audio Connectors
Depending on the operating system and the audio software, the six audio connectors (Fig. 11, pos. 7) can be operated as
audio input or output jacks (e.g. Line-In, Line-Out, Mic-In, 5.1 surround etc.).
