7. Product Description
KBox B-101 – User’s Guide (Version 1.00)
7.1. Front Side
7
4
2
3
1
4
5
6
Fig. 9: KBox B-101 – front view
1
AC IN power connector
2
Controls and indicators
3
Additional interface connectors
(routed from the internal onboard interfaces)
4
Ventilation openings at the front side
5
PCIE x16 Slot
6
Optional drive bay for removable HDD/SSD
7
Interfaces of the installed motherboard
7.1.1. Power Supply Unit (AC)
The 3-pin connector (Fig. 9, pos. 1) provides the power connection to a mains socket via a power cord. Please observe
section 10.1 „AC Power Connection“.
7.1.2. Controls and Indicators
1
Power button
2
Power LED
3
HDD LED
2
3
1
Fig. 10: KBox B-101 – Controls and Indicators
www.kontron.com
13
