7. Product Description

KBox B-101 – User’s Guide (Version 1.00)

7.1.2.1.

Power Button

Press this button (Fig. 10, pos. 1) to turn the system on and off.

Prerequisite:
The KBox B-101 must be connected to an appropriate AC mains power source.

Caution!

Please observe that turning OFF the system via the power button (see Fig. 10, pos.1) does not
disconnect the platform from the AC mains power source.

Even when the system is turned off via the power button (see Fig. 10, pos.1) there is still a standby-
voltage of 5 VSb on the motherboard.

The unit is only completely disconnected from the mains when the power cord is disconnected either
from the mains power source or from the unit. Therefore, the power cord and its connectors must always
remain easily accessible. The outlet of the AC power source must be located near to the device and be
easily accessible.

7.1.2.2.

Power LED and HDD Activity LED

The power LED (Fig. 10, pos. 2) and the HDD LED (Fig. 10, pos. 3) are located on the front side of the KBox B-101 and
indicate the system status.

Power LED
(green)

This LED (Fig. 10, pos. 2) lights up green when the system is turned on by the power button.

Prerequisite:
The system must be connected to the AC power source, using the power cable.

HDD-LED
(yellow)

This LED (Fig. 10, pos. 3) lights up during hard disk activity.

Do not press the eject button of the (optional) removable HDD/SSD, while the drive LED is lit or is
flashing.
