Page 41
Chapter 2: Installation
2-15
X9SCM/X9SCL(-F)
Rev.1.0
2-5 Connectors/IO Ports
The I/O ports are color coded in conformance with the PC 99 specification. See the
figure below for the colors and locations of the various I/O ports.
Back I/O Panel
1
2
3
4
5
6
7
8
9
Back I/O Panel
1. Keyboard (Purple)
6. COM 1
2. PS/2 Mouse (Green)
7. VGA
3. USB Port 0
8. LAN1
4. USB Port 1
9. LAN2
5. IPMI LAN (X9SCM-F/X9SCL-F/X9SCL+-F Only)
