1-8
X9SCM/X9SCM-F/X9SCL/X9SCL-F/X9SCL+-F User’s Manual
Motherboard Features
CPU Single Intel® Xeon E3-1200 series, 2nd generation
Intel Core® i3, Pentium®, Celeron® processor in an
LGA 1155 socket.
Memory Four (4) SDRAM DIMM slots support up to 32 GB of
DDR3 Unbuffered, ECC 1333/1066 memory
Supports dual-channel memory bus
DIMM sizes
UDIMM
1 GB, 2 GB, 4GB and 8GB
Chipset Intel® C204 Express (X9SCM Series)
Intel® C202 Express (X9SCL Series)
Expansion Slots Two (2) PCI Express 2.0 x8 slots
Two (2) PCI Express x4 in x8 slots, One (1) on the
X9SCL/X9SCL-F/X9SCL+-F
Integrated Graphics Matrox® G200eW
Network Connections One (1) Intel 82574L Gigabit Ethernet controller for
LAN 1, and one (1) Intel 82579 PHY for LAN 2. Note:
The X9SCL+-F features two (2) Intel 82574L Gigabit
Ethernet controllers, one each for LAN 1 and LAN 2.
Two (2) RJ-45 Rear IO Panel Connectors with Link
and Activity LEDs
Single Realtek RTL8201N PHY to support IPMI 2.0
LAN (X9SCM-F/X9SCL-F/X9SCL+-F Only)
I/O Devices SATA Connections
(X9SCM/X9SCM-F)
•
SATA-III Ports (6Gb/s)
•
Two (2) (I-SATA 0/1)
•
SATA-II Ports (3Gb/s)
•
Four (4) (I-SATA 2~5)
(X9SCL/X9SCL-F/X9SCL+-F)
•
SATA-II Ports
•
Six (6) (I-SATA 0~5)
RAID (Windows) RAID 0, 1, 5, 10
Onboard IPMI (X9SCM-F/X9SCL-F/X9SCL+-F Only)
IPMI 2.0 supported by the WPCM450 Server BMC
USB Devices
Two (2) USB ports on the rear IO panel (USB 0/1)
Six (6) USB header connectors for front access (USB
2/3, USB 4/5, USB 12/13)
One (1) Type A USB internal connector (USB 11)
Keyboard/Mouse
PS/2 Keyboard/Mouse ports on the I/O backpanel
