Chapter 1: Introduction

1-3

Motherboard Image (X9SCL/X9SCL-F)

Note: All graphics shown in this manual were based upon the latest PCB
Revision available at the time of publishing of the manual. The motherboard
you've received may or may not look exactly the same as the graphics
shown in this manual.
