ETX-DC®/ System Resources

The standard ETX®-DC Power management BIOS does support MARS (Mobile Application platform for Rechargeable
Systems). Further details about MARS are available at

Embedded Modules Division - Kontron

8.7 JILI-I2C Bus

I2C Address

Used For

Available

Comment

A0h

JILI-EEPROM

EEPROM for JILI-Data

8.8 K-Station / JIDA32 resources

8.8.1 I2C

BUS

Function

I2C 0

Internal / JIDA I2C

I2C 1

SM-Bus

I2C 2

JILI I2C

I2C 3

SDVO I2C

I2C 4

CRT I2C

8.8.2 Storage

Device

Function

EEPROM 0

JIDA EEPROM Area1 with 32 Bytes free

EEPROM 1

JIDA EEPROM Area 2 with 33 Bytes (reserved)

8.8.3 GPIO

Port

Function

GPIOs are not supported on ETX-DC®.

8.8.4 Hardware Monitor

Sensor

Function

Temp 0

CPU diode via onboard Winbond W83627

Temp 1

CPU DTS via onboard Winbond W83627

FAN 0

Onboard fan connector via Winbond W83627

Voltage 0

onboard Winbond W83627: CoreA

Voltage 1

onboard Winbond W83627: +3.3V

Voltage 2

onboard Winbond W83627: +5V
