ETX-DC®/ Specifications

3.5 Mechanical Specifications

Dimensions

95.0 mm x 114.0 mm (3.75” x 4.5”)

Height approx. 12 mm (0.4”)

3.6 Electrical Specifications

Supply Voltage

VCC: 5V DC +/- 5%

5V_Stb: 5V DC +/- 5% but always equal or lower VCC

Note: It is recommended to follow the ATX specification for voltage rise times which claims: "The output voltage

shall rise from ≤ 10% of nominal to within the regulation ranges … within 0.1ms to 20ms".

Supply Voltage Ripple

Maximum 100 mV peak to peak 0 – 20 MHz

Supply Current 5 V_SB

Typical 50 mA, peak up to 350 mA (S3)

Power Consumption

Detailed Power Consumption measurements in all states and benchmarks for CPU, Graphics and Memory performance
are available in Application Note KEMAP054 at

EMD Customer Section
