ETX-DC®/ ETX® Connectors
24
4.6 Connector X3 Signal Description
VGA Output
LVDS Flat Panel Interface (JILI)
The user interface for flat panels is the JUMPtec Intelligent LVDS Interface (JILI). The implementation of this
subsystem complies with the ETX® Specification. Implementation information is provided in the ETX® Design Guide.
Refer to the documentation for additional information.
Digital Flat Panel Interface (JIDI)
The ETX®-DC does not support the JUMPtec Intelligent Digital Interface (JIDI).
Serial Ports (1 and 2)
The ETX®-DC supports two serial interfaces (TTL). You can use COM2 for IrDA SIR operation. This feature is
implemented in the super I/O device, which is a Winbond 83627HF.
The implementation of the serial interface complies with the ETX® Specification. Implementation information is
provided in the ETX® Design Guide. Refer to the documentation for additional information.
Configuration :
The serial-communication interface uses I/O and IRQ resources. The resources are allocated by the BIOS during POST
configuration and are set to be compatible with common PC/AT settings. Use the BIOS setup to change some
parameters that relate to the serial-communication interface.
PS/2 Keyboard
The implementation of the keyboard interface complies with the ETX® Specification. Implementation information is
provided in the ETX® Design Guide. Refer to the documentation for additional information.
Configuration :
The keyboard uses I/O and IRQ resources. The BIOS allocates the resources during POST configuration. The resources
are set to be compatible with common PC/AT settings. Use the BIOS setup to change some keyboard-related
parameters.
PS/2 Mouse
The implementation of the mouse interface complies with the ETX® Specification. Implementation information is
provided in the ETX® Design Guide. Refer to the documentation for additional information.
Configuration :
