ETX-DC®/ ETX® Connectors
20
4.5 Connector X3 (VGA, LCD, Video, COM1 and COM2, LPT/Floppy, Mouse,
Keyboard)
4.5.1 Alternative pinning
Flat-Panel Interfaces
ETX®-DC modules can implement an LVDS flat-panel interface called JUMPtec Intelligent LVDS Interface (JILI). These
modules do not implement a parallel digital flat-panel interface called JUMPtec Intelligent Digital Interface (JIDI).
LVDS Interface Pinout (JILI)
Pin Signal Pin Signal
1 GND 2 GND
3 R 4 B
5 HSY 6 G
7 VSY 8 DDCK
9 DETECT#** 10 DDDA
11 LCDDO16 12 LCDDO18
13 LCDDO17 14 LCDDO19
15 GND 16 GND
17 LCDDO13 18 LCDDO15
19 LCDDO12 20 LCDDO14
21 GND 22 GND
23 LCDDO8 24 LCDDO11
25 LCDDO9 26 LCDDO10
27 GND 28 GND
29 LCDDO4 30 LCDDO7
31 LCDDO5 32 LCDDO6
33 GND 34 GND
35 LCDDO1 36 LCDDO3
37 LCDDO0 38 LCDDO2
39 VCC * 40 VCC *
41 JILI_DAT 42 LTGIO0**
43 JILI_CLK 44 BLON#
45 BIASON** 46 DIGON
47 COMP** 48 Y**
49 SYNC** 50 C**
Notes: *To protect external power lines of peripheral devices, make sure that:
- the wires have the right diameter to withstand the maximum available current
- the enclosure of the peripheral device fulfils the fire-protection requirements of IEC/EN60950.
**This signal is not supported on the ETX®-DC.
