Kontron SMARC-sAT30 User Manual
Page 58
User’s Guide
58
SMARC sAT30 Edge finger
NVIDIA T30 CPU
Notes
S21
AFB4_IN
Not used
S22
AFB5_IN
Not used
S23
AFB6_PTIO
Not used
S24
AFB7_PTIO
Not used
S25
GND
S26
SDMMC_D0
L27
SDMMC3_DAT0
S27
SDMMC_D1
J26
SDMMC3_DAT1
S28
SDMMC_D2
J28
SDMMC3_DAT2
S29
SDMMC_D3
K26
SDMMC3_DAT3
S30
SDMMC_D4
Not used
S31
SDMMC_D5
Not used
S32
SDMMC_D6
Not used
S33
SDMMC_D7
Not used
S34
GND
S35
SDMMC_CK
G30
SDMMC3_CLK
S36
SDMMC_CMD
J29
SDMMC3_CMD
S37
SDMMC_RST#
K24
SDMMC3_DAT6
S38
AUDIO_MCK
C27
CLK1_OUT
S39
I2S0_LRCK
C29
DAP2_FS
S40
I2S0_SDOUT
G27
DAP2_DOUT
S41
I2S0_SDIN
F27
DAP2_DIN
S42
I2S0_CK
C28
DAP2_SCLK
Through a 33 ohm
Series resistor (R295)
S43
I2S1_LRCK
R4
DAP3_FS
S44
I2S1_SDOUT
M3
DAP3_DOUT
S45
I2S1_SDIN
N3
DAP3_DIN
