Kontron COMe-cOH2/COMe-cOH6 User’s Guide
www.kontron.com
56
8 BIOS Operation
The COMe-cOH# COM supports carrier board SPI devices. Carrier board SPI boot
support is new with COM Express Rev 2.
8.1 Determining the BIOS Version
The COMe-cOH# COM has AMIBIOS®8 installed on the onboard 8-Mbit firmware hub.
To determine the AMI® BIOS version, press the Pause key on your keyboard
immediately, as soon as you see the following text display in the upper left
corner of your screen:
» AMIBIOS © 2011, American Megatrends, Inc.
» BIOS Date: 09/22/2011 13:36:23 Ver: 2.11.1210
» Kontron® BIOS Version < EEOHR 0.09 x64>
» © Copyright 2002-2011 Kontron
8.2 Setup Guide
The AMIBIOS Setup Utility changes system behavior by modifying the BIOS
configuration. The setup program uses a number of menus to make changes and
turn features on or off.
NOTE: Selecting incorrect values may cause system boot failure. Load setup
default values to recover by pressing .
8.2.1 Start AMIBIOS ®
8 Setup Utility
To start the AMIBIOS® setup utility, press when the following string
appears during boot-up:
Press to enter Setup
The Info menu then appears.
The Setup screen has several sections:
Setup Screen Location Function
Menu Bar Top Lists and selects all top
level menus.
Legend Bar Right side bottom Lists setup navigation
keys.
Item Specific Help Window Right side top Help for selected item.
Menu Window Left center Selection fields for
current menu.
