Pin Signal Description Type Terminatio
n
Comment
C12 USB_SSRX3- SuperSpeed USB
Data Receive
Path 3-
Not connected nc nc
C13 USB_SSRX3+ SuperSpeed USB
Data Receive
Path 3+
Not connected nc nc
C14 GND Power Ground PWR - -
C15 DDI1_PAIR6+ Digital
Display
Interface
Not connected nc nc
C16 DDI1_PAIR6- Digital
Display
Interface
Not connected nc nc
C17 RSVD Reserved Not connected nc nc
C18 RSVD Reserved Not connected nc nc
C19 PCIE_RX6+ PCI Express
Differential
Receive Pair
6+
DP-I
C20 PCIE_RX6- PCI Express
Differential
Receive Pair
6-
DP-I
C21 GND (Fixed) Power Ground PWR
C22 PCIE_RX7+ PCI Express
Differential
Receive Pair
7+
Not connected nc nc
C23 PCIE_RX7- PCI Express
Differential
Receive Pair
7-
Not connected nc nc
C24 DDI1_HPD Digital
Display
Interface Hot-
plug detect
I-3.3
C25 DDI1_PAIR4+ Digital
Display
Interface
Not connected nc nc
C26 DDI1_PAIR4- Digital
Display
Interface
Not connected nc nc
C27 RSVD Reserved Not connected nc nc
C28 RSVD Reserved Not connected nc nc
C29 DDI1_PAIR5+ Digital
Display
Interface
Not connected nc nc
C30 DDI1_PAIR5- Digital Not connected nc nc
