Kontron COMe-cOH2/COMe-cOH6 User’s Guide
www.kontron.com
47
5 Special Features
5.1 Watchdog Timer (WDT)
The watchdog timer is managed via the super I/O component, the Nuvoton
NCT5577D.
The implementation complies with the COM Express® specification. Timer modes
1, 2, and 3 are supported. For additional implementation information, refer
to the PICMG COM Express® Design Guide on the PICMG website
5.2 General Purpose Input and Output (GPIO)
The COMe-cOH# COM provides four interrupt-capable general purpose inputs and
four general purpose outputs that can be accessed through the module
connector described in the pin-out lists, in Section 4.1. The GPIO interface
can be enabled in the BIOS setup.
Table 14: GPIO COM Express Pin-Outs
Bit of GPIO
Port0
Function COM Express Pin
0 GPI0 A54
1 GPI1 A63
2 GPI2 A67
3 GPI3 A85
4 GPO0 A93
5 GPO1 B54
6 GPO2 B57
7 GPO3 B63
5.3 ACPI Suspend Modes and Resume Events
The COMe-cOH# COM supports the following suspend modes:
» S0 (Normal on)
» S3 (Suspend to RAM)
» S4 (Suspend to Disk)
» S5 /WOL(soft-off, WOL enabled)
» S5 (soft-off, WOL disabled)
» S5 ECO deep soft-off
