» TDP: 2.3W
» Package: 23mmx23mm
Display Interfaces
» Features: 2 Digital Display Interfaces 0 and 1 (as defined by COM
Express Rev. 2 Type 6)
Dual independent display pipes - two active display
interfaces allowed
Display Port – resolution to 2560 x 1200 x 60 Hz
HDMI/DVI - resolution to 1920 x 1200 x 60 Hz
Single channel (18 bit) LVDS channel A (as defined by COM
Express Rev. 2 Type 6)
Analog VGA, with max resolution up to 2560x1600 at 60 Hz
(on COM Express A-B connector)
Storage
» SATA: 4xSATA 2.0 supporting up to 6.0 Gbps transfer rate
Onboard Devices:
» Ethernet: Intel® 82574L GbE Controller 10/100/1000 Mbit
» Ethernet Features: S0 or S5 power, under BIOS control, supporting
WakeOnLAN
» USB 3.0 Host Controller Renesas uPD720200A( Type-6 only)
» DP Analogix ANX3110 DP 24-bit 2-channel LVDS Converter (Type-
2 only)
» Security: N/A
» Watchdog Timer: SIO implementation
BIOS enables and configures watchdog in the CPLD
Watchdog has the option to generate NMI after the delay has
expired
» Power Management: BIOS-enabled ACPI 3.0 power managementfor supported
OS
Additional Interfaces:
» LPC bus: Yes, to COM Express A-B connector
» SMBus: Yes, to COM Express A-B connector
» I 2 C: Yes, the I 2 C bus can be implemented using an FCH SMBus
port. (COM Express Rev 2.0 specifies that the I 2 C bus shall
be active in S5)
» GPIO: Yes, 8xGPIO, 4 GPI and 4 GPO (inputs are interrupt-capable)
