Kontron COMe-cOH2/COMe-cOH6 User’s Guide
www.kontron.com
35
Pin
Signal
Description
Type
Terminatio
n
Comment
D77
RSVD
Reserved
Not connected
nc
nc
D78
PEG_TX8+
PCI Express
Graphics
Transmit Data
Lane 8 Positive
DP-O
D79
PEG_TX8-
PCI Express
Graphics
Transmit Data
Lane 8 Negative
DP-O
D80
GND (Fixed)
Power Ground
PWR
-
-
D81
PEG_TX9+
PCI Express
Graphics
Transmit Data
Lane 9 Positive
DP-O
D82
PEG_TX9-
PCI Express
Graphics
Transmit Data
Lane 9 Negative
DP-O
D83
RSVD
Reserved
Not connected
nc
nc
D84
GND
Power Ground
PWR
-
-
D85
PEG_TX10+
PCI Express
Graphics
Transmit Data
Lane 10
Positive
DP-O
D86
PEG_TX10-
PCI Express
Graphics
Transmit Data
Lane 10
Negative
DP-O
D87
GND
Power Ground
PWR
-
-
D88
PEG_TX11+
PCI Express
Graphics
Transmit Data
Lane 11
Positive
DP-O
D89
PEG_TX11-
PCI Express
Graphics
Transmit Data
Lane 11
Negative
DP-O
D90
GND (Fixed)
Power Ground
PWR
-
-
D91
PEG_TX12+
PCI Express
Graphics
Transmit Data
Lane 12
Positive
DP-O
D92
PEG_TX12-
PCI Express
Graphics
DP-O
