7.6 K-Station Resources
Table 21: I
2
C
BUS Function
I2C 0 Internal
I2C 1 SMBus
I2C 2 Internal (for slow devices)
I2C 4 TBD
Table 22: Storage
Device Function
EEPROM 0 EEPROM Area1 with 32 Bytes (free to
use)
EEPROM 1 EEPROM Area 2 with 33 Bytes (reserved)
Table 23: GPIO
Port Function
IO-Port 0 GPIO Port, Bit 0-3: Input, Bit 4-7:
Output
Table 24: Hardware Monitor
Sensor Function
Temp 0 CPU ACPI temperature (measured with
Nuvoton NCT5577D SIO HWM)
Temp 1 Module temperature (internal IC
temperature of onboard HWM)
FAN 0 Module CPU fan sensor (measured with
NCT5577D SIO HWM)
Voltage 0 Nuvoton NCT5577D SIO Voltage Sensor
0: CoreA
Voltage 1 Nuvoton NCT5577D SIO Voltage Sensor
1: VRAM
Voltage 2 Nuvoton NCT5577D SIO Voltage Sensor
2: +3.3V
