www.kontron.com 53
User Guide
COMe-bP5020
USAGE: 1. Display available configurations:
=> sconf info
List of available base configurations:
*< >* Stored base configuration
-[ ]- New base configuration (work in progress)
============+-=====================================================================
No SRDS | Bank1 Bank1 Bank1 Bank2 Bank3
PRTCL | A-D E-H I-J A-D A-D
============+-=====================================================================
|
*[ 1]* 0x11 | PCIe1 PCIe2 DBG GbE[4x1] SATA[2x1]
|
< 2> 0x13 | PCIe1 PCIe2 DBG GbE[4x1] XAUI
|
< 3> 0x15 | PCIe1 PCIe2 DBG XAUI SATA[2x1]
|
< 4> 0x17 | sRIO2 [@5.0] sRIO1 [@5.0] DBG GbE[4x1] SATA[2x1]
|
< 5> 0x17 | sRIO2 @3.125 sRIO1 @3.125 DBG GbE[4x1] SATA[2x1]
|
Board's Port Configuration for base config 1 (serdes protocoll 0x11):
Option/Setting | Value # command option
---------------+--------+------------------------------------
PCIe1 : @5.0G # sconf set pcie1 <@5.0G | @2.5G | off>
PCIe2 : @5.0G # sconf set pcie2 <@5.0G | @2.5G | off>
Aurora : off # sconf set aurora
dTSEC1 : on # sconf set dtsec1
dTSEC2 : on # sconf set dtsec2
dTSEC3 : on # sconf set dtsec3
dTSEC4 : on # sconf set dtsec4
SATA1 : on # sconf set sata1
SATA2 : on # sconf set sata2
USB : host # sconf set usb
UART : 4wire # sconf set uart <4wire | 2wire>
SDHC : ext # sconf set sdhc
GPIOA : gpio # sconf set gpioa
GPIOB : gpio # sconf set gpiob
GPIOC : gpio # sconf set gpioc
=>
2. Select new base conf iguration
=> sconf select 1
New base configuration 1
=>
Table 46: sconf Command (cont’d)
